Dull blades lead to defects
Product yield is key in the semiconductor industry. Finding and understanding the root cause of defects is therefore an important process to be able to predict the occurrence of a root cause and prevent future defects.
One step in the production of IC’s is the so-called “wafer dicing”. In this step, wafers are cut (diced) into many pieces, each containing a circuit. Each of these pieces is called a die.
One method for dicing is “blade dicing” which, due to its mature technology and low cost compared to other methods, is still widely used. The downside is that blade dicing induces mechanical stress which leads to chipping. Especially when the blade is becoming dull.
As a few nanometers of damage to a die is already a problem, and humans cannot see particles smaller than about 50nm, operators cannot see if blades are wearing out. Therefore, predicting when a blade will be worn out and replacing it before it does, can help engineers prevent lost production time, reduce waste and improve quality. As wafer dicing comes after 5+ months of wafer production time, preventing defects can have a significant effect on yield and quality.
One of our customers challenged us to significantly reduce chipping caused by blade wear out. With the starting point at a 4% defect ratio, we set ourselves the goal to reduce it by at least 50%.
